MPC Testing Under ASTM D7843: Why the Correct Patch Micron Rating and Patch Material Are Not Optional
A practical warning for reliability engineers, oil-analysis managers, and turbine-oil users
In reliability engineering, we often make major maintenance decisions from a few numbers on an oil-analysis report. One of those numbers is the MPC value, or Membrane Patch Colorimetry result. For turbine oils, hydraulic control fluids, and EHC systems, the MPC result is widely used to assess the tendency of the oil to form varnish-related insoluble degradation products.
But there is a serious and often overlooked problem: some laboratories are not using the correct membrane patch micron rating or the correct patch material when performing MPC testing. This is not a small procedural mistake. In MPC testing, the patch is not just a piece of filter paper. It is a critical part of the measurement system.
ASTM D7843 defines MPC testing as a method where insoluble contaminants from an in-service turbine oil sample are extracted onto a membrane patch and the patch color is measured by a spectrophotometer, with the result reported as a CIELAB ∆E value. The standard also describes the test as a condition-monitoring trending tool, not a stand-alone diagnosis.
The message is simple:
Wrong patch, wrong result.
Wrong micron rating, wrong capture efficiency.
Wrong patch material, wrong chemistry and optics.
Wrong ASTM version, wrong basis for comparison.
The membrane patch is part of the test method, not a substitute item
ASTM D7843 specifies the use of a 47 mm, 0.45 µm nitrocellulose membrane filter. The standard also states that apparatus variations, especially filter membranes and vacuum pump settings, can significantly affect results. If an alternate membrane filter is used, the user must establish that it gives equal results.
This point is extremely important. A laboratory cannot casually replace the specified membrane with another patch and still treat the result as fully comparable ASTM D7843 data unless equivalence has been properly demonstrated.
A membrane with a different pore size, different polymer, different surface structure, different thickness, or different background color can change the amount of insoluble material captured and the way that material appears to the spectrophotometer. MPC is both a filtration test and an optical measurement. Changing the patch changes both.
Why the 0.45 µm micron rating matters
The 0.45 µm rating is not a random number. It defines the particle and insoluble-material capture boundary for the ASTM method. Lubricant-generated varnish precursors and degradation products are often very fine, polar, soft, and partly insoluble. They do not behave like normal hard dirt particles.
If a lab uses a membrane with a larger pore size, such as 0.8 µm or 1.0 µm, some fine color bodies may pass through the patch or may not be retained in the same way. The reported MPC ∆E can become artificially low. The oil may look healthier on paper than it really is.
If a lab uses a smaller pore size, such as 0.2 µm, it may capture material that the ASTM method was not designed to capture under the same conditions. The result may become artificially high, filtration may become slower, the patch may load differently, and edge staining or deposit disturbance may become more likely.
The biggest problem is not only whether the number becomes higher or lower. The biggest problem is that the trend becomes unreliable. A turbine oil trend showing MPC values of 8, 12, 18, and 25 only has meaning if the test method remained consistent. If the lab changed patch pore size in the middle of the trend, the plant may be looking at a laboratory artifact instead of a real oil-condition change.
Why patch material matters as much as pore size
Two patches can both be labeled 0.45 µm and still behave differently. Micron rating does not fully describe a membrane. Patch material affects surface chemistry, solvent compatibility, pore structure, wetting behavior, deposit adhesion, drying behavior, and optical background.
ASTM D7843 specifies nitrocellulose. If a laboratory uses nylon, PES, PTFE, PVDF, mixed cellulose ester, glass fiber, paper, or another substitute without a documented equivalence study, the reported MPC value may no longer represent the same ASTM-defined measurement.
This matters because varnish-related color bodies are not only mechanically filtered; they may also be retained by surface interaction with the membrane. A different material can adsorb polar degradation products differently. It can also change the whiteness and texture of the patch background, which directly affects the spectrophotometer reading.
ASTM D7843 requires a spectrophotometer capable of measuring a standard 15 mm target using 0°/45° geometry, a 10° observer, visible-range measurement from 400 nm to 700 nm, and CIELAB indices.
That means the patch must not only collect the insolubles correctly; it must present them consistently to the instrument. A substitute patch may capture a different amount of deposit and may also make the same deposit appear optically different.
How wrong patches create false decisions in the plant
A wrong MPC result can lead to wrong reliability decisions.
A false low MPC result can make a plant believe the oil is clean when varnish precursors are actually increasing. This may delay varnish-removal action, oil change planning, root-cause analysis, servo-valve inspection, reservoir cleaning, or filtration upgrades. In turbines and hydraulic control systems, this delay can be costly.
A false high MPC result can create the opposite problem. The plant may purchase varnish mitigation equipment unnecessarily, change oil too early, challenge the lubricant supplier without basis, or start intrusive maintenance based on a number that was produced by a non-standard test setup.
The most dangerous case is a trend break. If a lab changes patch supplier, patch material, pore size, solvent, vacuum setting, instrument, or incubation practice but continues reporting the data as normal, the reliability engineer may interpret a laboratory-method change as a machine-condition change.
The test is sensitive to more than the patch
The patch is central, but ASTM D7843 also controls several other variables that affect the MPC result.
The sample must be protected from UV exposure. The standard notes that oil is sensitive to indoor and outdoor UV sources and that fluorescent light can contain UV components. The sample is heated at 60 °C to 65 °C for 23 h to 25 h, then stored at 15 °C to 25 °C away from UV light for an incubation period of 68 h to 76 h. Samples analyzed too early may produce fewer color bodies on the patch and therefore a lower ∆E value.
The filtration process also matters. ASTM D7843 describes vacuum control, solvent rinsing, careful washing of the membrane, drying, and instrument standardization using a clean-solvent patch as the white background reference. It also states that if deposits fail to remain on the dry membrane, the test must be repeated.
This is why a lab cannot fix a wrong patch by simply “adjusting technique.” If the membrane requires different vacuum, different washing behavior, different drying time, or different handling, the method has been changed.
Why the latest ASTM D7843 version matters
Following “ASTM D7843” is not enough. The exact revision matters.
The uploaded standard is ASTM D7843-25, approved in February 2025 and published in March 2025. The summary of changes from D7843-21 identifies changes that may affect use of the standard, including the addition of heptane in reagents and procedure, added repeatability and reproducibility information for heptane, and a revised bias statement.
ASTM’s current public listing identifies ASTM D7843-25e1 / D7843-25E01 as the active version and lists earlier versions such as D7843-25, D7843-21, D7843-18, D7843-16, and D7843-12 separately. (ASTM International | ASTM)
This matters for audits and data integrity. A lab may say, “We follow ASTM D7843,” but the reliability engineer should ask, “Which revision?” If the lab SOP is based on an old version, the plant may be comparing current data against a method that is not aligned with the latest active standard.
The practical requirement should be:
The laboratory shall perform MPC testing according to the latest active ASTM D7843 version, unless a different revision is specifically agreed in writing and clearly reported.
Special caution for phosphate ester EHC fluids
Phosphate ester EHC fluids need additional care in interpretation. ASTM D7843 includes appendix guidance explaining that turbine lube oils often form amber-brown color bodies from thermo-oxidative degradation, while phosphate ester fluids may also form black insoluble color bodies from high-temperature breakdown pathways. Both can produce high ∆E values, but black deposits do not necessarily mean the same thing as amber-brown varnish deposits.
The visual examples on page 5 are very useful: the black patch is associated with soot and has high ∆E with little ∆(a*+b*) contribution, while the brown patch is associated with thermal degradation products related to varnish and has high ∆E with significant ∆(a*+b*) contribution. The same page states that complete oil analysis is needed to determine the cause of membrane patch color and characterize fluid degradation products.
For EHC systems, do not interpret ∆E alone. Ask the lab for the patch image, ∆E, a*, b*, ∆(a*+b*), and, where practical, patch weight. ASTM D7843 notes that end users may request patch weight and ∆(a*+b*) in addition to ∆E, and that recording these values is best laboratory practice for trending.
What reliability engineers should ask the oil lab
Many reliability engineers never visit the oil laboratory. That is common, but it creates risk. The lab’s procedures, consumables, and instruments may directly influence the numbers used for plant decisions.
A practical MPC lab audit should ask for evidence, not just verbal confirmation.
Ask the lab:
- Which ASTM D7843 revision is your controlled SOP based on?
The answer should identify the exact revision, not just “ASTM D7843.” - What membrane patch do you use?
Ask for manufacturer, catalog number, lot number, diameter, pore size, and material. - Is the membrane 47 mm, 0.45 µm nitrocellulose?
If not, ask for the validation study proving equivalent results. - Which solvent is used?
Confirm whether petroleum ether/petroleum spirit or heptane is used, and do not mix trends without understanding the method change. - How is UV exposure controlled?
Ask about bottle type, storage, shipping, heating, incubation, and lab lighting control. - How is incubation controlled and reported?
ASTM D7843 requires incubation after heating to be reported with the ∆E value. - How is vacuum controlled?
Since the standard specifically warns that vacuum setting can affect results, ask for the vacuum setting and verification records. - How is the spectrophotometer standardized?
Ask whether a clean-solvent patch is used to establish the background white reference. - Are deviations reported?
ASTM D7843 requires deviations from the standard methodology to be noted in the report. - Has anything changed in the historical trend period?
Ask about changes in patch supplier, patch type, solvent, instrument, vacuum pump, operator procedure, sample aging, or reporting format.
Minimum wording for a purchase specification
Reliability teams can prevent many problems by including clear technical wording in their oil-analysis contract or purchase order.
Suggested wording:
“MPC testing shall be performed according to the latest active ASTM D7843 version unless otherwise agreed in writing. The membrane filter shall be 47 mm, 0.45 µm nitrocellulose, or a documented ASTM-equivalent membrane validated by comparative testing. The report shall identify the ASTM revision used, solvent used, incubation period after heating, ∆E value to one decimal place, and all deviations from the method. For phosphate ester EHC fluids, the report shall include the patch image and, where available, a, b, ∆(a*+b*), and patch weight.”**
This wording is simple, but it forces method discipline.
What to do if previous MPC data may have used the wrong patch
Do not immediately discard the historical data, but do not treat it as fully ASTM-comparable until verified.
First, ask the lab when the membrane patch type, supplier, material, or pore size changed. Then split the trend into separate periods. If possible, send duplicate samples to a lab that confirms full ASTM D7843 compliance. For critical turbines or EHC systems, run a short bridging study using the old lab and a confirmed compliant lab on the same samples.
If an alternate membrane was used, ask for comparative data over low, medium, and high MPC samples. One or two similar results are not enough to prove equivalence across the operating range.
Final message for the industry
MPC testing is too important to be treated casually. It is used to make decisions about varnish control, filtration, oil change timing, servo-valve reliability, turbine availability, and lubricant health. But the MPC value is only meaningful when the method is controlled.
The patch micron rating and material are not minor details. They define what is captured, how it is retained, how it dries, and how it is seen by the spectrophotometer. A non-standard patch can create false confidence, false alarms, and broken trends.
Reliability engineers should not wait for a varnish problem before questioning the lab. Ask now. Verify the patch. Verify the ASTM revision. Verify the solvent. Verify the reporting. Verify deviations.
A good oil-analysis program is not built only on frequent sampling. It is built on trustworthy, method-compliant, repeatable data. In MPC testing, that starts with one small but critical item: the correct 47 mm, 0.45 µm nitrocellulose membrane patch.
A patch photo alone cannot prove that the wrong patch was used. It can show visual red flags that should trigger questions about membrane material, micron rating, vacuum, rinsing, drying, and ASTM D7843 compliance.
What MPC patch photos may look like when the wrong patch is used
One of the most useful things a reliability engineer can request from the oil laboratory is the actual MPC patch photo. The number is important, but the image often tells a story that the number alone cannot tell.
ASTM D7843 is built around extracting insoluble oil-degradation products onto a 47 mm, 0.45 µm nitrocellulose membrane patch, then measuring the color by spectrophotometer as a CIELAB ∆E value. The standard also warns that variations in apparatus, especially filter membranes and vacuum settings, can significantly affect the results, and that alternate membranes must be proven to give equal results.
So, when the wrong patch material or wrong micron rating is used, the patch image may look unusual. It may not always look “wrong” to the untrained eye, but it can show warning signs.
1. Patch looks unusually clean or too pale
A wrong patch with a larger pore size or poor affinity for varnish-related insolubles may allow fine color bodies to pass through. The photo may show a very light tan, weak yellow, or almost clean white patch even when the machine history, previous MPC trend, servo-valve symptoms, or varnish deposits suggest otherwise.
This is dangerous because the reported MPC ∆E may be falsely low. The reliability engineer may believe the oil is improving when the lab simply failed to capture the same fraction of insoluble degradation material.
Photo warning sign: pale patch, weak color, low visual loading, but field symptoms or historical trend suggest varnish risk.
2. Patch looks too dark, overloaded, or artificially severe
A membrane with a smaller pore size, different surface chemistry, or stronger retention of fine material may collect more material than the ASTM method intended. The patch may look very dark, heavy, dense, or overloaded.
This can create a falsely high MPC value. The plant may overreact by changing oil, installing varnish removal equipment, or blaming the lubricant supplier when the result was influenced by non-standard membrane selection.
Photo warning sign: patch looks much darker than historical trend would suggest, especially if the lab recently changed patch supplier, membrane type, or method version.
3. Patch has a dark outer ring or “coffee-ring” pattern
A good MPC patch should have a reasonably representative deposit pattern. If the photo shows a strong dark ring near the edge, a lighter center, or a very uneven deposit boundary, this may indicate non-uniform filtration, poor membrane wetting, vacuum issues, wrong membrane material, poor funnel sealing, or improper rinsing.
This matters because the spectrophotometer measures a defined area of the patch. If the deposit is not uniform, small differences in measurement location can change the reported ∆E.
Photo warning sign: dark edge ring, light center, crescent-shaped staining, or non-uniform deposit distribution.
4. Patch looks blotchy, mottled, or cloudy
A wrong membrane material may wet differently with petroleum ether or heptane. It may also interact differently with oil degradation products. The resulting patch can look blotchy, cloudy, patchy, or uneven instead of having a consistent color field.
This can cause poor repeatability. Two duplicate tests from the same oil may produce noticeably different patch photos and different ∆E values.
Photo warning sign: random cloudy zones, blotches, uneven brown areas, or inconsistent color density across the patch.
5. Patch shows specks, fibers, or gritty contamination
If the wrong filter type is used, especially a depth-type media, paper-type filter, or incompatible membrane, the patch may show specks, loose fibers, gritty particles, or random dark dots. This may not represent varnish-related insoluble color bodies. It may represent contamination, filter shedding, dirty glassware, poor solvent cleanliness, or non-standard filtration behavior.
ASTM D7843 is not simply a dirt test. It is a colorimetric method for lubricant-generated insoluble color bodies. A speckled patch can drive the spectrophotometer reading higher while giving a misleading impression of varnish severity.
Photo warning sign: visible particles, lint-like fibers, black dots, or gritty spots scattered over the membrane.
6. Deposit flakes off or does not remain on the membrane
This is a major warning sign. ASTM D7843 states that if deposits fail to remain on, or fall off, the dry membrane, the test must be repeated.
If the patch photo shows bare spots, missing deposit areas, flaking, cracked deposit islands, or washed-off sections, the result should not be accepted casually. This can happen when the membrane material is not suitable, the washing step is too aggressive, the deposit does not adhere properly, or drying/handling is poor.
Photo warning sign: missing deposit, flakes, bare white areas inside the deposit zone, or material visibly detached from the patch.
7. Patch background is not properly white
The membrane itself is part of the optical system. If the wrong membrane has a different background color, texture, gloss, thickness, or transparency, the spectrophotometer may “see” a different baseline. ASTM D7843 uses a clean-solvent patch to establish the background white reference before color determination.
A non-standard membrane may look slightly gray, cream, translucent, shiny, rough, or fibrous. Even before oil is filtered, the patch background may be different from the ASTM-intended membrane.
Photo warning sign: patch background looks gray, yellowish, shiny, translucent, textured, or fibrous compared with a clean nitrocellulose membrane.
8. Patch color is black, not amber-brown
This point needs careful interpretation. A black patch does not automatically mean the wrong patch was used. ASTM D7843 itself shows that, for in-service EHC fluids, a black patch can indicate soot or high-temperature breakdown products, while a brown patch can indicate thermal degradation products associated with varnish. The standard notes that black patches may have high ∆E with little ∆(a*+b*) contribution, while brown varnish-related patches have high ∆E with significant ∆(a*+b*) contribution.
However, if a lab reports only ∆E and does not provide a*, b*, ∆(a*+b*), patch weight, or a patch image, the reliability engineer may misinterpret the result. A black patch may represent soot, not classic amber-brown varnish potential.
Photo warning sign: black or charcoal patch reported only as “high MPC” without a*, b*, ∆(a*+b*), patch weight, or interpretation.
Practical photo review guide for reliability engineers
When reviewing MPC patch photos, look for these red flags:
| Patch photo appearance | Possible concern | Reliability risk |
|---|---|---|
| Too clean or very pale | Larger pore size, wrong material, poor retention, early analysis | False low MPC |
| Too dark or overloaded | Smaller pore size, excessive retention, non-standard membrane | False high MPC |
| Dark edge ring | Poor sealing, uneven flow, wrong wetting behavior, vacuum issue | Poor repeatability |
| Blotchy or cloudy | Wrong membrane chemistry or inconsistent wetting | Unstable trend |
| Speckled or gritty | Contamination, fiber shedding, dirty solvent/glassware | Misleading high ∆E |
| Deposit falls off | Poor adhesion, wrong membrane, improper wash/dry | Test should be repeated |
| Black patch | Could be soot, especially in EHC fluids | Do not interpret ∆E alone |
| Brown/amber patch | More consistent with varnish-type color bodies | Confirm with trend and full oil analysis |
Reliability engineers should request the MPC patch photo with every high, abnormal, or trend-changing MPC result. The photo should not be used as the only diagnostic tool, but it is a powerful quality check. A pale patch, dark edge ring, blotchy deposit, loose deposit, speckled contamination, non-white membrane background, or unexpected black patch should trigger questions about the membrane material, pore size, vacuum setting, solvent, drying, and ASTM D7843 revision used.
For phosphate ester EHC fluids, the photo is especially important. ASTM D7843 shows that black patches and brown patches can both produce high ∆E values, but they may represent different degradation mechanisms. A black patch may indicate soot or high-temperature breakdown products, while a brown patch is more associated with thermal degradation products related to varnish. Therefore, for EHC fluids, the lab should be asked to provide the patch image, ∆E, a, b, ∆(a*+b*), and patch weight where available.**
The key message is simple: the MPC number should not travel alone. It should travel with the patch photo, ASTM revision, membrane specification, solvent used, incubation time, and any method deviation. Without that context, a reliability engineer may be making varnish-control decisions from incomplete or non-comparable data.
